Grinding Capacity Maximum, W x L 12" x 24"
Table Working Surface, W x L .......... 10.813" x 23.75"
Grinding Width Capacity, Maximum .......... 12"
Grinding Length Capacity, Maximum .......... 24"
Height Under 12" Grinding Wheel .......... 13.5"
Table Longitudinal Travel .......... 27.5"
Table Cross Travel .......... 12"
Grinding Wheel Diameter 12"
Grinding Wheel Width 1.5"
Grinding Wheel Hole Diameter 5"
Table Longitudinal Feeds, Range .......... 1 to 100 FPM
Table Cross In-Feeds, Range .......... .04 to .4 IPR
Spindle Vertical Feeds, Range .......... .0001 to .005 IPR
Power Rapid Vertical Traverse .......... 14 IPM
Grinding Wheel Spindle Motor .......... 5 HP/1730 RPM
Hydraulic System Motor .......... 2 HP
Power Elevation Motor .......... 1/2 HP
Electrical System .......... 230-460/3/60
