Power Elevation
Power Clamping
Coolant
| Arm Length | 4' | 1.2 m |
| Column Dia. | 13.38" | 339.85 mm |
| Power | 7.2 hp | 5.4 kW |
| RPM | 0 RPM | 0 RPM |
| Dimensions | 36" x 86" x 87" High | 36" x 86" x 87" High |
| Weight | 5000 | 5000 |
Spindle center to column surface, max.: 52-1/2"
Spindle center to column surface, min.: 11-5/8"
Diameter of spindle: 3-1/16"
Vertical spindle travel: 11-13/16"
Spindle taper: MT #4
Spindle speeds (12): 38 – 1985 RPM
Feeds (6): 0.0032 – 0.04 in / rev
Horizontal travel of spindle head: 40-3/4"
Base to spindle, maximum: 51-3/4"
Base to spindle, minimum: 13"
Vertical travel of arm: 27-1/2"
Motor: 5 HP (3.7kW) / 1710 RPM
Volts: 220 / 440
This equipment has been sold. Similar equipment available now is shown below.
